DAH Solar Solar Module 500 Wp - bifacial
- Power: 500 watts
- Dimensions: 1962 x 1134 x 30 mm
- N-type TOPCon technology
- bifacial
- 26.6 kg
Tax included. Shipping calculated at checkout
Your legal guarantee rights

Product description
DAH Solar 500 Wp Solar Module - Glass-Glass, Frame Black & Bifacial
Highest efficiency thanks to bifacial design and N-Type TOPCon technology
The highly efficient DAH Solar double-glass 500 W solar module sets new standards in solar power generation. With innovative N-Type TOPCon technology, it delivers more than 3% higher power per watt compared to PERC modules - perfect for roofs, gardens, or marine applications. It also comes with a 30-year performance warranty, providing long-term security.
Optimal energy yield thanks to two-sided light utilization
Bifacial modules utilize sunlight on both sides: while the front captures direct light, the back generates electricity from reflected radiation. This can increase the yield by up to 25% depending on the surface and mounting conditions - especially effective on reflective surfaces such as snow or light-colored ground.
Innovative TOPCon cells for maximum performance
- Rectangular high-performance cells with optimized energy yield
- Higher electricity generation (5-25%) compared to conventional modules
- Better performance in low light thanks to an optimized temperature coefficient
- Lower power degradation for long-term efficiency
Double-glass technology for durability
- Improved encapsulation for greater resistance
- Enhanced mechanical strength against external influences
- Protection against microcracks, acids, alkalis, salt spray, and UV radiation
- Minimization of power losses through hotspot prevention
Technical highlights of the DAH Solar 500W module
- 500 watts of power with bifacial cell technology
- N-Type TOPCon technology for higher efficiency and durability
- Anti-reflective glass for better light absorption
- Weatherproof IP68 junction box and MC4 compatibility
- Corrosion-resistant aluminum frame, also suitable for saline environments
- 3 integrated bypass diodes to reduce power losses during partial shading
- ISO 9001 certified manufacturing for the highest quality standards
The DAH Solar Frame Black 500W module impresses with its maximum efficiency, durability, and innovative technology – an ideal solution for high-performance solar systems.
| Technical Data | DAH SOLAR 500W |
| Rated power | 500 W |
| Max. daily yield (summer) | 3000 Wh/d |
| Voltage (Umpp) | 37.10 V |
| Current (Impp) | 13.48 A |
| Open-circuit voltage (Voc) | 43.70 V |
| Short-circuit current (Isc) | 14.48 A |
| Cell efficiency | 22.11 % |
| Cell material | N-Type cells |
| Bypass diode | Integrated |
| Weight | 26.6 kg |
| Dimensions | 1962 x 1134 x 30 mm |
