SunWare SW 20163 white, 33 Wp
- Power: 33 watts
- Cable length: 3 m
- Weight: 1.4 kg
- 100% waterproof and resistant to saltwater
Tax included. Shipping calculated at checkout
Your legal guarantee rights

Product description
SunWare SW Solar Module Series 20 white 33Wp 12V: High-performance energy solutions for marine applications
Product introduction: Experience maximum energy efficiency at sea with the Series 20 marine solar modules, designed for walk-on installation directly on deck. These modules, manufactured in Germany, are not only extremely robust and salt-water resistant, but also ideal for direct bonding or bolting to the deck, with no need for rear ventilation. Equipped with a single connection cable at the front, these modules allow for easy installation.
Performance and flexibility: The Series 20 marine solar modules are characterized by their high performance even in diffuse light, thanks to the exclusive use of top-class solar cells. Their semi-flexible design adapts perfectly to deck curves and allows for a maximum flexibility of 3%. Thanks to the special laminate construction, the modules are 100% sea- and salt-water resistant, making them ideal for use in harsh marine environments.
Design features: These modules are not only lightweight and compact, but also offer outstanding power output thanks to the built-in monocrystalline PERC high-performance solar cells, protected by EVA laminate and ETFE top layers. The Series 20 marine solar modules can be securely mounted using screws, bonding, or SunWare clips, and are walk-on even when permanently installed with boat shoes.
Installation flexibility: The included 3-meter connection cable and the option to route the cable through the deck increase installation flexibility.
Application and reliability: Series 20 marine solar modules are a reliable energy source specially developed for demanding sea and salt-water applications. They are the ideal choice for discerning boat owners seeking high functionality and long-lasting durability in an aesthetically pleasing design.
| Technical data | SunWare SW 20163 |
| Rated power | 33 W |
| Max. daily yield (summer) | 198 W |
| Voltage (Umpp) | 22.00 V |
| Current (Impp) | 1.50 A |
| Open-circuit voltage (Voc) | 25.80 V |
| Short-circuit current (Isc) | 1.60 A |
| Number of cells | 38 |
| Carrier plate | Aluminum sandwich |
| Cable outlet | Front side |
| Weight | 1.4 kg |
| Dimensions | 426 x 481 mm |
