Victron Multi RS19 Solar 48/6000/100-450/100

  • Combination of inverter and charger
  • Pure sine wave 230 V AC
  • Two AC outputs
  • PowerControl and PowerAssist functions
  • Parallel and three-phase operation possible

Sale price1.837,90 €
Vorbestellbar

Tax included. Shipping calculated at checkout

SKU: 300-3381

Re-stocking soon
Versandbereit in: 7 - 9 Werktagen

Product description

Victron Multi RS19 Solar 48/6000/100-450/100 – Hybrid Inverter with Dual MPPT for 48-V Systems

The Victron Multi RS19 Solar combines several core components in one device: a powerful 48-V inverter, a battery charger, and an integrated dual MPPT solar charge controller. This makes it a strong foundation for flexible 48-V hybrid systems – whether you want to optimize self-consumption, build a partially autonomous system, or create a reliable backup power supply.

The combination of DC-coupled PV charging (via MPPT) and classic 230-V power supply allows the system to operate both grid-connected and off-grid. Monitoring is conveniently handled via display and VictronConnect via Bluetooth; additionally, VE.Can, VE.Direct, and BMS-Can are available for integration into Victron systems (GX devices, Energy Meter, Monitoring).

Four operating modes: suitable for your application

  • Hybrid mode: solar surpluses are stored in the battery and used later
  • Backup mode: automatic switchover in the event of a grid failure
  • Off-grid mode: grid-independent operation
  • Generator mode: optimizes the use of a generator and can reduce operating times

PowerControl & PowerAssist: handle load peaks without overload

With PowerControl, you can define a maximum grid or generator current to prevent overloads. PowerAssist supplements short-term load peaks with battery power – and ensures that the battery is recharged afterwards. This is particularly helpful when the available grid or generator power is limited, but you still want to briefly operate high-power consumers.

Integrated dual MPPT: up to 2 PV trackers for direct battery charging

The integrated solar charge controller operates with two PV trackers. Each tracker supports up to 3 kW (voltage range 65–450 V), meaning a total of up to 6 kWp of DC-coupled PV power. If you want to expand your PV array later, you can additionally increase the PV capacity via additional solar charge controllers or AC-coupled PV inverters.

Robust, efficient, and built for demanding environments

The Multi RS19 Solar is designed for continuous operation: with an efficiency of up to 96.5%, fan-assisted cooling, a wide temperature range of -40 to +65 °C, and a robust steel enclosure (IP20). A programmable relay as well as a temperature and voltage sensor round off the system.

Your benefits at a glance

  • 3-in-1: Inverter + battery charger + dual MPPT in one device
  • For 48-V hybrid systems: grid-connected or off-grid
  • Four operating modes (Hybrid, Backup, Off-Grid, Generator) for flexible use
  • PowerControl & PowerAssist: protects against overload and supports load peaks
  • Dual MPPT: 2 trackers, each up to 3 kW (65–450 V), total up to 6 kWp DC-coupled
  • Monitoring & Integration: Bluetooth/VictronConnect, display, VE.Can/VE.Direct/BMS-Can
  • Efficient & robust: up to 96.5% efficiency, IP20 steel enclosure, -40 to +65 °C

If you are looking for a powerful, integrated centerpiece for a 48-V system – with direct PV connection via two MPPTs and typical Victron system integration – the Victron Multi RS19 Solar is a very compelling solution.






Technical data Victron Multi RS 19 Solar 48/6000
DC input voltage range 38 - 62 V
AC output 230 V
cont. output power 46 V / 52 V 4800 W / 5300 W
Peak power 9 kW 3 sec. / 7 kW 4 min.
Short-circuit output current 45 A
Temperature range - 40 °C to + 65 °C
Protection class IP 20
Weight 12.2 kg
Dimensions 133 x 483 x 430 mm
