Victron Orion-Tr Smart 24/12-20A DC-DC Charger Isolated (240W)

  • 240W
  • Input voltage range: 16 - 35 V
  • Adjustable output voltage: 10 - 15 V
  • 3-stage charger with integrated Bluetooth
  • for use in dual battery systems
  • with motor run detection mechanism
  • also suitable for lithium batteries
  • many devices can be connected in parallel
  • Galvanically isolated with 200V DC between input, output and housing

Sale price154,76 €

Tax included. Shipping calculated at checkout

SKU: 300-3307

In stock
Versandbereit in: 1 - 3 Werktagen

Product description

Orion-Tr Smart isolated DC-DC 24/12 20A charger

The Orion-Tr Smart 24/12 20A 240W charger is a professional, DC to DC adaptive 3-stage charger with integrated Bluetooth.

For use in dual battery systems in vehicles or on boats, where the (intelligent) alternator and the starter battery are used to charge the service battery. The device can be monitored and programmed via Bluetooth and can be remotely controlled via a remote on/off switch. It features an engine detection mechanism.

Ready for Bluetooth Smart

  • Changing the settings and updating the charger when new software features become available can be done with any Bluetooth-enabled smartphone, tablet or other device.
  • Instant Readout: The VictronConnect app can display the most important data, including warnings and alarms, on the device list page without requiring a connection to the product.

Fully programmable

  • Battery charging algorithm (configurable) or fixed output.
  • Intelligent generator compatibility: Engine detection.


Adaptive 3-stage charging algorithm: Constant current – Constant voltage – Float

  • For lead batteries, it is important that during shallow discharges the absorption time is kept short to avoid overcharging the battery. After a deep discharge, the constant voltage duration is automatically extended to ensure that the battery charges completely.
  • For lithium batteries, the absorption time is fixed, with a default setting of 2 hours. Alternatively, a fixed output voltage can be selected.


Remote on/off
A remote on/off switch or relay contact can be connected to the two-pole plug.
Alternatively, the H connection (right) of the two-pole plug can be connected to a battery positive terminal or the L connection (left) of the two-pole plug to the battery negative terminal (or for example to the body
of a vehicle).

All models are short-circuit proof and can be connected in parallel to increase the output current.
An unlimited number of devices can be connected in parallel.

Over-temperature protection
At high ambient temperatures, the output current is reduced.

Protection class IP43
If the screw terminals on the device are installed facing downwards.

Screw terminals
No special tools are required for installation
