WATTSTUNDE® SOLA Frame Mono 100Wp HV

WATTSTUNDE® SOLA Frame Mono 100 Wp HV – Compact & highly efficient thanks to HV technology

With the WATTSTUNDE® SOLA Frame Mono 100 Wp HV, you're choosing a compact, high-performance solar module that operates at 41.76 V. This means more efficient operation even at greater distances between the module and charge controller, and the option to use thinner and more cost-effective cables.

Technical specifications at a glance

• Nominal power: 100 Wp
• Voltage: 41.76 V | Current: 2.4 A
• Cell efficiency: 21.8 – 22.5%
• Dimensions: 1040 × 515 × 30 mm
• 2 bypass diodes
• Frame: Aluminum with anodized coating (hollow chamber profile frame)
• Surface: 3.2 mm, high-transmissive, AR-coated, tempered glass
• Junction box: IP68
• Connection: 90 cm cable with MC4-compatible connectors
• 10-year warranty period | 25-year performance guarantee (80%)

Robust & durable

The robust hollow chamber profile frame offers high strength – even under harsh conditions. The highly transmissive tempered safety glass (ESG) with anti-reflective properties increases light transmission and protects against weathering and mechanical stress. The IP68-rated junction box ensures safe, weatherproof operation.

Easy installation

Thanks to pre-assembled MC4-compatible connectors and a 90 cm cable, the module is ready for immediate use. Multiple modules can be easily connected – allowing you to flexibly adapt your system to your requirements.

Your benefits at a glance

• HV: 41.76 V – less cable loss, more efficiency
• High cell efficiency up to 22.5%
• Reliable performance in partial shading thanks to bypass diodes
• Weatherproof & robust: ESG-AR glass, IP68 junction box
• Quick assembly with MC4 compatibility
• Long-term security guaranteed: 10-year product warranty & 25-year performance warranty

The WATTSTUNDE SOLA Frame Mono 100 Wp HV is your efficient solution for self-sufficient energy – whether in your camper van, garden, or boat. With HV, you can utilize your solar energy with even less loss and greater reliability.
